Solar Power Kits
Item details
Capacity | Inverter – 2 KVA, Battery – 150 Ah x 2 |
Running Load Combination | 5 CFL + 5 Tube light + 4 Ceiling Fan + 2 Television + 1 computer + 1 Double door Refrigerator |
Standard backup | 8 - 10 hours |
Technology | Inverter – Sine Wave, Battery – Tubular plates |
Warranty | Inverter – 24 months, Battery 60* months |
Weight | Inverter – 20 Kg, |
Operating Voltage | 100 V – 290 V |
Battery Full Recharge Time | 10-12 hours |
Protections | Overload, deep discharge, short-circuit, Reverse polarity |
Backup time*
Load | 500 W | 400 W | 300 W | 200 W | 100 W |
Duration | 4 hrs 40 mint | 6 hrs | 9 hrs | 15 hrs | 37 hrs |
Technical details
Dry Weight | Filled Weight | Overall Dimensions of Containers (mm) | Boost Charging | Trickle Mode Charging | ||||
±5%Kg. | ±5%Kg. | Length (+/-3) mm | Width (+/-3) mm | Height (+/-3) mm | Starting rate (Amp) | Finishing rate (Amp) | Min. (mA) | Max (mA) |
29.7 | 54.7 | 502 | 191 | 412 | 15.1 | 7.6 | 126 | 504 |
Display Indications
- Mains available - yes
- Battery Charging – yes
- Battery Charging level in % -yes
- Inverter switched on – yes
- Low Battery indication- yes
- Overload Indication – yes
Luminous Solar 1500 Combo is designed to give power supply for 8-10 hours to homes having severe power cuts and unreliable electricity supply. It is a 1.5 KVA Power plant which can run a Peak Load upto 1200 Watts.
Suitable for small home.
Inverter - 1.5 KVA, 2 years warranty
Battery -2 Nos. 150 Ah - Tall Tubular, 5 years replacement Warranty
Solar Panel - 4 Nos. 250 Watt - 25 years performance Warranty
Ideal for running - 4 Ceiling Fan, 4 CFL, 4 Tube light, 2 Television, 2 Laptop/Mobile Charging
Backup time*
Load | 500 W | 400 W | 300 W | 200 W | 100 W |
Duration | 4 hrs 20 mint | 6 hrs | 9 hrs | 15 hrs | 36 hrs |
Luminous NXG1400 is a powerful hybrid inverter with 40 Amp inbuilt charge Controller. It is the most intelligent solar system which gives priority to solar power use to save on electricity bills. The Solar Inverter charges the battery from grid and Solar panels. If Sun energy is available then It charges the battery from solar Panel and if Solar is not available, then the inverter charges the battery from Mains/Grid. It can charge the battery and supply solar power to connected load if solar generation is sufficient otherwise it gives first priority to solar battery charging and then supply additional power to connected loads.
In this bundle
1 x NXG inverter
1 x Luminous 250 Watt solar panel
1 x 150AH Luminous Tubular battery
Key Features-
- First of its kind Home UPS that delivers both AC & DC output
- Up to 1000 Watt PV Module solar panel compatibility
- Intelligent fuzzy logic for maximum utilization of solar energy
- Pure sine wave output provides better performance & safety to the connected load
- Electricity savings of 3 to 5 units per day.
Product Descriptions
Key Feature | Solar hybrid Inverter with inbuilt PWM Charge controller |
Running Load | 6 lights, 1 Television, Decoder, Computer (Please note No Fridge) |
Battery Support | All Brands & All Types |
Battery System | Double battery / 24V |
Weight | 12 Kg. |
Dimension in CM | 37 * 31 *13 |
Technical Details
Wave Type | Pure Sine Wave |
Rated Capcity | 1100 VA |
Voltage Window (eco mode): | 100 V – 290V |
Voltage window (UPS mode) | 180V – 260 V |
Full Battery Recharge Time | 10-12 Hrs |
Charge Controller Rating | 40 Amp/ 24V |
DC Load Output | 12 V / 20 Amp |
Protection | Overload, deep discharge, short-circuit, Battery low cut off |
Additional Features
- Battery Selection Type – Tubular/ Flat / Gel or VLRA
- Charging selection type – Intelligent charging / Normal Charging
- Voltage regulation mode – Eco / UPS
- Inverter reset key - Yes
Display
- Mains available - yes
- Battery Charging through Mains - yes
- Battery Charging through Solar Panel – yes
- Voltage regulation display – yes
- Power savings - yes
- Load output through Battery - yes
- Low Battery Indication – yes
- Overload Indication – yes
