Solar Inverters

Any-Grid™ Hybrid Inverter Charger The Phocos Any-Grid Inverter Charger Series (Pure Sine Wave Hybrid) represents Phocos’ most versatile line of inverters/chargers. Flexibility and reliability are key characteristics of this product line, with a strong potential for cost saving opportunities in real world conditions. The Any-Grid Hybrid Inverter converts DC (Direct Current) energy into AC (Alternating Current), with multiple advantages beyond standard inverters. This product includes an integrated MPPT charge controller and can function as an AC to DC battery charger, which provides flexible energy access solutions in a broad range of applications. The battery can be charged from solar and/or an AC source (public grid or generator), with easily programmable priorities. It can function without an AC source or alternatively even without solar, as a pure uninterruptible power supply (UPS). When the utility grid or AC generator fails, the Any-Grid Hybrid Inverter immediately switches to ‘Off-Grid’ mode within 10 ms (typical, in UPS mode) to securely power the loads at all times. Solar can be set as the priority energy source to save electricity costs. The Any-Grid Hybrid Inverter can function in a battery-free mode. In this mode, for installations with stable public grids, grid energy consumption can be reduced without the need to invest in a costly battery bank. Additionally, power can be supplied directly to loads from the grid and solar simultaneously. This unit comes with a quality, integrated MPPT charge controller. The controller accepts particularly high PV voltages, allowing many PV modules to be connected in series, decreasing installation cost and avoiding combiner boxes. Up to 9 inverters can be connected in parallel or 3-phase for up to 45 kW of synchronized AC power.

Output power (15min) :500W; converts 12VDC to 230VAC Max. efficiency up to 95% LED indicators Operational USB output 5VDC/1A Safe design with input and output electrical isolation Does not support lithium battery

Technical specifications Manufacturer Model IP500-12 EAN Code 4260558570684 Article number 3100500 Input rated voltage of the battery 12VDC Input voltage range 10.8 ~ 16VDC Fuse 2 * 32VDC / 35A Output voltage 220VAC (± 5%) / 230VAC (-10% ~ + 5%) Continuous power up to + 45 ℃ 400W Output power up to 15 min. 500W Efficiency 92% IP protection IP20 Operating temperature -20 ℃ ~ + 45 ℃ Dimension 214 × 105.5 × 57.7mm Weight 0.9kg
